| Item | 10G SFP+ Module |
| Part Status | Active |
| Form Factor | SFP+ |
| Max Data Rate | 10G |
| Max Cable Distance | 300m@OM3/400m@OM4 |
| Wavelength | 850NM |
| Connector | Duplex LC |
| Media | MMF |
| Optical Component | VCSEL/PIN |
| TX Power | -7.3~-1dBm |
| Receiver Sensitivity | < -11.1dBm |
| Receiver Overload | -1dBm |
| Power Consumption | <1W |
| DDM/DOM | DDM Supported |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Protocols | IEEE 802.3ae, SFF-8472, SFF-8431, SFF-8432, SFP+ MSA Compliant, CPRI, eCPRI |
| Warranty | 5 Years |
| Sample | Available |
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module.
We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
We are a specialized manufacturer of magnetic telecom and networking components, such as RJ45 connectors, LAN transformers, RJ11 connectors, and SFP modules.
Yes, we can offer you free samples to test quality, but shipping costs should be covered by the buyer.
Products are ready to ship for stock items, and 15-30 days for mass production.
We provide a one-year guarantee period and offer online technical support 24 hours a day.
Yes, please contact us with your requirements so we can proceed with a detailed discussion.
We have 19 years of production experience and have been a trusted partner for global clients for many years.
